Alfen Twin 4XL

Alfen Twin 4XL is designed for a high volume streetscape environment and suitable for any semi-public or public space with a 3-phase supply. It offers two back-to back sockets in a vandal-proof steel pillar with a curved top surface so waste cannot be left on the charger. The pillar can be brand wrapped if required. The charger incorporates an RFID reader and MID-meter for financial settlement.

Alfen Twin 4XL features

A dual socket, with advanced smart functionality, to withstand the streetscape environment

  • At the public parking place the Twin can charge many vehicles without a problem
  • Cutting-edge and sophisticated smart functions
  • Designed for integration and maximum charging speed
  • On the high street the rugged design of the Twin comes into its own
  • Made to endure: robust, safe and reliable
  • Choose and change management system easily
General characteristics

Manufacturer: Alfen

Model: Twin 4XL

Connector type: 2x Type 2 socket, in accordance with IEC62196-2

Dimensions: 1385 x 335 x 220 mm

Weight: Approx. 40 kg

Protection Rates: IP54/IK10

Electrical characteristics

Rated power: 7.4kW (1-phase) 22kW (3-phase)

Rated courent: 64A per phase

Rated Voltage: 400V (3x230V)

Rated frequency: 50 Hz

Operating temperature: -25°C to 40°C

Communication & Interface

Connectivity: GPRS (2G) LTE Cat M1 (4G) Ethernet/LAN

Supported mobile communication bands: 2G: EGPRS quad-band: 850 / 900 / 1800 / 1900 MHz 4G: LTE Cat M1 bands: 3, 8, 20
